Kategorija proizvoda: JIC adapteri za hidraulične ugradnje za cijevni priključak struje
Standard proizvoda: ISO 8434-2, SAE J514.
Materijal: čelični čelik, nehrđajući čelik ili legura bakra.
Kraj JIC cijevi do drugog krajnjeg spoja, kako slijedi: BSP zatvarač, E, G, H tipovi, armatura serije ISO 6149, fitinzi JIS B2351, ISO 11926 i SAE J1926 ORB fitinzi, DIN 3852 i ISO 1179 okovi, ISO 9974 fitinzi itd.
1JG9-OG 90 ° IZLAZI JIC MUŠKI 74 ° CONE / BSP MALE O-RING Dimenzioni grafikon na sljedeći način:
DIO NO. | NIT | O-RING | DIMENZIJE | |||||||||
E | F | F | A | B | S1 | S2 | ||||||
1JG9-04-02OG | 7/16 "X20 | G1 / 8 "X28 | O011 | 24.5 | 26.2 | 11 | 14 | G1 / 8 "X28 | O011 | |||
1JG9-04-06OG | 7/16 "X20 | G3 / 8 "X19 | O113 | 27.5 | 36.8 | 16 | 22 | G1 / 4 "X19 | O111 | |||
1JG9-04OG | 7/16 "X20 | G1 / 4 "X19 | O111 | 26.6 | 31.3 | 14 | 19 | G3 / 8 "X19 | O113 | |||
1JG9-05-04OG | 1/2 "X20 | G1 / 4 "X19 | O111 | 26.5 | 31.8 | 14 | 19 | G1 / 2 "X14 | O115 | |||
1JG9-05-06OG | 1/2 "X20 | G3 / 8 "X19 | O113 | 27.5 | 35.8 | 16 | 22 | G3 / 4 "X14 | O119 | |||
1JG9-05-08OG | 1/2 "X20 | G1 / 2 "X14 | O115 | 31.5 | 43.2 | 22 | 27 | G1 "X11 | O217 | |||
1JG9-06-04OG | 9/16 "X18 | G1 / 4 "X19 | O111 | 26.9 | 31.3 | 14 | 19 | |||||
1JG9-06-08OG | 9/16 "X18 | G1 / 2 "X14 | O115 | 32.5 | 43.2 | 22 | 27 | |||||
1JG9-06OG | 9/16 "X18 | G3 / 8 "X19 | O113 | 28.5 | 35.8 | 16 | 22 | |||||
1JG9-08-04OG | 3/4 "X16 | G1 / 4 "X19 | O111 | 32 | 33.5 | 19 | 19 | |||||
1JG9-08OG | 3/4 "X16 | G1 / 2 "X14 | O115 | 34.8 | 43.2 | 22 | 27 | |||||
1JG9-08-06OG | 3/4 "X16 | G3 / 8 "X19 | O113 | 32 | 36.8 | 19 | 22 | |||||
1JG9-08-12OG | 3/4 "X16 | G3 / 4 "X14 | O119 | 37.9 | 49.3 | 27 | 32 | |||||
1JG9-10-06OG | 7/8 "X14 | G3 / 8 "X19 | O113 | 37.8 | 39.2 | 22 | 22 | |||||
1JG9-10-08OG | 7/8 "X14 | G1 / 2 "X14 | O115 | 37.8 | 43.2 | 22 | 27 | |||||
1JG9-10-12OG | 7/8 "X14 | G3 / 4 "X14 | O119 | 41 | 49.3 | 27 | 32 | |||||
1JG9-12OG | 1.1 / 16 "X12 | G3 / 4 "X14 | O119 | 44.2 | 49.3 | 27 | 32 | |||||
1JG9-12-08OG | 1.1 / 16 "X12 | G1 / 2 "X14 | O115 | 44.2 | 46.5 | 27 | 27 | |||||
1JG9-12-16OG | 1.1 / 16 "X12 | G1 "X11 | O217 | 48 | 53 | 33 | 41 | |||||
1JG9-16OG | 1,5 / 16 "X12 | G1 "X11 | O217 | 49 | 53 | 33 | 41 | |||||
1JG9-16-12OG | 1,5 / 16 "X12 | G3 / 4 "X14 | O119 | 49 | 53 | 33 | 32 | |||||
1JG9-16-20OG | 1,5 / 16 "X12 | G1.1 / 4 "X11 | O222 | 53.8 | 58 | 41 | 50 | |||||
1JG9-20OG | 1,5 / 8 "X12 | G1.1 / 4 "X11 | O222 | 55.5 | 58 | 41 | 50 | |||||
1JG9-20-16OG | 1,5 / 8 "X12 | G1 "X11 | O217 | 55.5 | 58 | 41 | 41 | |||||
1JG9-24-16OG | 1.7 / 8 "X12 | G1 "X11 | O217 | 62.5 | 63 | 48 | 41 | |||||
1JG9-24-20OG | 1.7 / 8 "X12 | G1.1 / 4 "X11 | O222 | 62.5 | 63 | 48 | 50 | |||||
1JG9-24OG | 1.7 / 8 "X12 | G1.1 / 2 "X11 | O224 | 62.5 | 63 | 48 | 55 | |||||
